Create Standby with Oracle 19.16?

I hit Bug 34446152 – [DATAGUARD_BRKR] 19.16 onward broker shows „ORA-16705: internal error in Data guard broker“ (Doc ID 34446152.8)

If you decide to create an DG Environment, do it with 19.14 or 19.20 but not with 19.15-19.19. I have not alot of infos about this Bug. But it is a … maybe you will HIT-Bug.

Okay after Upgrade (19.20)

Following Guide helps to startup DG-Standby from previouse cloned VM:

FYI: This Template VM is preconfigured to be ready for Standby Cloning with this steps:

tomdg01:

mkdir /app_oracle/fra/C10P_A/standbylog

sql+ /app_oracle/local/dbsetup/19/crdb/11_standby.sql

vi /etc/oratab => don't start the DB after cloning vm
change listener.ora -- check standby entries
change tnsnames.ora -- check standby entries

now we can clone

Okay now you can start und Setup the Standbyside:

tomdg02:

change listener.ora -- remove the primary and active the standby part
change tnsnames.ora -- same here
mkdir  /app_oracle/fra/C10P_B
cp /tmp/demo_stby.ctl /app_oracle/data/C10P_A/ctrl1.ctl
cp /tmp/demo_stby.ctl /app_oracle/fra/C10P_A/ctrl2.ctl
mkdir  /app_oracle/fra/C10P_B


sqlplus "/as sysdba"

startup nomount;
alter system set db_recovery_file_dest='/app_oracle/fra/C10P_B' scope=spfile;
alter system set db_unique_name=C10P_B scope=spfile;
shutdown immediate;
startup mount;

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE DISCONNECT FROM SESSION;


exit;

lsnrctl start C10P

Now we can start the Primary instance tomdg01

tomdg01:

sqlplus "/as sysdba"
startup;
exit;

lsnrctl start C10P

--test the connection best on both sides!

sqlplus sys/@dg_c10p_a;
sqlplus sys/@dg_c10p_b;

Now lets enable the DG:

dgmgrl sys/@dg_c10p_a

create configuration C10P as primary database is c10p_a connect identifier is DG_C10P_A;
add database c10p_b as connect identifier is DG_C10P_B maintained as physical;

edit database c10p_b set property ApplyLagThreshold=0;
edit database c10p_b set property TransportLagThreshold=0;
edit database c10p_a set property ApplyLagThreshold=0;
edit database c10p_a set property TransportLagThreshold=0;
edit database c10p_a set property 'logxptmode' ='sync' ;
edit database c10p_b set property 'logxptmode' ='sync' ;

enable configuration ;

-- alter system switch logfile --
show configuration;
show database c10p_b;
show database c10p_a;

The Broker shows the Current status of the Standby

After a while..

DGMGRL> show configuration

Configuration - c10p

  Protection Mode: MaxPerformance
  Members:
  c10p_a - Primary database
    c10p_b - Physical standby database

Fast-Start Failover:  Disabled

Configuration Status:
SUCCESS   (status updated 54 seconds ago)
